Single Pack High Build Line Marking Paint

2 Colour(s) Available

  • Application By Brush Roller & Suitable Spray
  • Fast Dry Time In as Little as 2-4 Hours Touch Dry
  • Quick & Easy To Use Perfect For Light To Medium Traffic
  • Suitable For Concrete, Metal, Wood, Stone & Brick
  • Multi-Buy Discounts
  • Free Delivery Available

Regular price
£62.99 Inc. VAT
Sale price
Regular price
Exc. VAT
Sold out
Unit price
Tax included. Shipping calculated at checkout.
Download Our Colour Charts

Free delivery is available for this product. Order today!

Advice Line

Need more information about our products? Give us a call on 01902 954948 or email us at

This product is not suitable for the following
  • Tiles of any sort
  • Unprimed plastic
  • Bare aluminium (you will need a suitable etch primer)
  • Untreated galvanised steel (Mordant solution first)
  • A hot surface that reaches above 106 degrees (C) (you will need high temperature paints)

The colours shown on the images are for guidance only. The displayed colour will depend on your monitor and browsers. The finished colour therefore may not be as shown here.

All pictures are for illustration purpose only - 1 & 2.5 Litre cans are not screen-printed cans.



Universal PU

High Build Line Marking Paint

High Build Line Marking Floor Paint, specially formulated for concrete or metal floors where light foot traffic willl occur to mark out lines and enhance safety in your industrial space with ease. Ideal for factory, warehouse, and shop floors, this line paint not only provides clear markings but also offers a protective coating with chemical resistance. Due to the products UV resistance this can be used both internally and externally.

Single Pack High Build Line Marking Floor Paint is made from a polyurethane enamel, ensuring a durable coating once fully dry. Its mirror-like gloss finish adds a professional touch to concrete floors and other suitably primed substrates. Say goodbye to dull and worn-out floors, and welcome a fresh and glossy look with our High Build Line Marking Floor Paint. Efficiently mark out lines and enhance safety in your industrial space with ease.

For Two Pack Epoxy Floor Paints suitable for heavy traffic areas like vehicles please Click here




Key Facts

  •  Can be brushed and rolled
  • Do not pre seal concrete with latex or PVC sealers paint will not ad here
  • Easy clean high gloss finish
  • Touch Dry 2-4 hours
  • Over coat 12-24 hours
  • Thinners suitable T0001 White Spirit
  • Covers Approx. 8 square metres per litre (this does not account for the method of application, absorption of substrate or wastage)
  • Suitable for light to medium foot traffic (Two pack epoxy floor paint is required for vehicles)
  • Two coats recommended for best results

Mixing and Thinning

Make sure you use a mixer on a slow running drill, pallet knife or a broom stick that reaches the bottom of the can and mixing should take place for 3-5 mins to ensure all the content is properly mixed together to avoid colour and or drying problems.
Thinners required are White Spirit T0001.
If thinning is required when applying by a brush or roller start by gradually adding 5% but do not thin more an 10% as the paint won’t cover As our coatings are heavily pigmented separation can easily occur and you can have colour float, for example a green paint can seem blue before mixing, this is one of the reasons mixing your paint before use is essential.

Application - Painting over existing paint

Step 1 - Check suitability of the product to the existing paint. We recommend you try a sample area first.

Step 2 Clean and Abrade -

  • Make sure the existing paint is in good condition prior to painting, then lightly abrade to provide a key for good intercoat adhesion.
  • If there is flaking paint this must be removed prior to painting.
  • For any parts that has rusted you will need to sand the rust back to the bare metal and spot prime with the appropriate primer.
  • Ensure substrate is clean of any dirt, oil, or grease.

Step 3 Topcoat- Once you have completed the following steps you can apply your top coat.


Application - Painting a bare substrate

Step 1 Clean - Ensure substrate is clean of any dirt, oil, or grease.

Step 2 Prime – If you are painting bare concrete you will need to thin the first coat by 20% to ensure it impregnates the concrete , this will act as the primer.

If you are painting metal you will need our metal primer Click Here

Step 3 Topcoat – 12-24 hours after applying the primer you can add your first coat of topcoat. Wait another 12-24 hours and then apply the second coat.



Mild Steel – If you are painting mild steel you will need our Metal Primer to view this please Click here

Wood, Concrete, Stone or Brick - No primer required 1st coat will prime and seal. You will find that these kind of substrates will be porous, we recommend that on your first coat thin by 20% to ensure it impregnates the substrate. Then after 12-24 hours apply the second coat un thinned.


Good preparation of the floor is paramount to an excellent long lasting finish. Make sure Floor is clean from dust, dirt, moisture, oil etc before painting. and never pre seal the floor prior to painting with latex or PVC sealers paint will not adhere.


New Concrete Floors  will need time to green this generally is a period of 3-6 months from when the concrete floor is laid, we say 3-6 months as it depends on the thickness of the concrete and quality, it’s always best ask the supplier and fitter of the concrete floor as to how long to wait till painting.





Paint Calculator

Calculate Your Solvent Paint

Solvent Paint Calculator in Metres

Total Sqm:

Quantity Needed:

Quantities are approximates per coat, we cannot allow for wastage and or any absorption that may occur with porous substrates.

Solvent Paint Calculator in Feet

Total Sqf:

Quantity Needed:

Quantities are approximates per coat, we cannot allow for wastage and or any absorption that may occur with porous substrates.

Additional Information
